Steam Laundry Flatwork Ironer , Commercial Ironing Equipment Tension Adjusting Structure

Steam  Laundry Flatwork Ironer , Commercial Ironing Equipment Tension Adjusting Structure
Steam  Laundry Flatwork Ironer , Commercial Ironing Equipment Tension Adjusting Structure

Large Image :  Steam Laundry Flatwork Ironer , Commercial Ironing Equipment Tension Adjusting Structure

Product Details:
Place of Origin: China
Brand Name: Evergreen
Certification: CE
Model Number: YZI-3000, YZII-3000, YZIII-3000, YZIV-3000, YZI-3300, YZII-3300, YZIII-3300, YZIV-3300
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: export pallet/full packing, one 20' container can fit 3 sets of 100kg or 4 sets of 50kg washer extractors
Delivery Time: 20-40 days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 100 sets one month
Detailed Product Description
Length: 3300mm 3000mm 2800mm 2500mm, 2000mm 1800mm Roll Number: 1, 2, 3, 4, 5
Heating: Steam, Gas, Electric Voltage: 380, 400, 450, 220
Application: Hotel, Laundry, Washing Plant, Railway, Hospital After-sales Service: Free Parts, Online Support, Video Instruction
High Light:

commercial ironing equipment

,

flat work ironer machine

Laundry Iron machine



The heat methord of our industrial flatwork ironer can be steam heat, electric heat or gas heat. The ironing speed can be ajusted according to steam supply condition and thickness of textile.



The steam with pressure is supplied through roll (rolls) so that the ironing area can be heated evenly and effectively.



Driven by the sprocket structure and working with tension adjusting structure, the flatwork ironer run stably and get great ironing quality.



High speed reducing rate and low noice as a result of the reducer installed.


Spindle tape drive is adopted instead of canvas, which can make tranferrence smoothly.


The steam inlet is sealed with rotary joint to avoid leakage and ensure long service life.



Technical information of Laundry Iron machine



Item Unit YZIII-3300 YZIII-3000 YZIII-2800
Quantity of roller   three three three

Roller

Diameter

Length

mm

mm

800

3300

800

3000

800

2800

Ironing speed (variable) m/min 0 - 10 0 - 21 0 - 21
Steam pressure mpa 0.4 - 0.6 0.4 - 0.6 0.4 - 0.6
Steam inlet size mm DN40 DN40 DN40
Steam consumption Kg/h 410 380 350
Motor power Kw 2.2 2.2 2.2
Water trap size mm DN20 DN20 DN20
Dimension (LxWxH) mm 4360x3400x1320 4060x3400x1320 4060x2400x1320
Weight kg 4200 3700 3200





Item Unit YZII-3300 YZII-3000 YZII-2800
Quantity of roller   two two two

Roller

Diameter

Length

mm

mm

800

3300

800

3000

800

2800

Ironing speed (variable) m/min 0 - 16 0 - 16 0 - 16
Steam pressure mpa 0.4 - 0.6 0.4 - 0.6 0.4 - 0.6
Steam inlet size mm DN40 DN40 DN40
Steam consumption Kg/h

280





265 250
Motor power Kw 1.5 1.5 1.5
Water trap size mm DN20 DN20 DN20
Dimension (LxWxH) mm 4360x2400x1320 4060x2400x1320 3860x2400x1320
Weight kg 3100 3000 2800
