| Rated Capacity (dry Loading): | 100kg/230lb | Drum D×L (inner Size) Mm: | ∮1240×840 |
|---|---|---|---|
| CylinderD×L (inner Size) Mm: | 30/60 | Motor Power KW: | 7.5 |
| High Light: | coin washer and dryer,commercial front load washing machine |
||
1. Large door opening for easy loading and unloading.
2. High-density flat hole technology of drum,perforated V-ribs for better cleaning result.
3. Anti-corrosion,tub and all metal part connect with water are AISI 304 stainless steel ensure long lifespan.
4. Spring and shock absorber structure ,absorb vibration rate is up to 97%, freestanding.
5. Stainless steel soap box, unique tilt stainless steel door for not leakage.
6. High spin testing under large capacity of unbalanced loading ensure long lifespan of structure.
7. 300 G-fator,standard double water inlet,save water and time.
Product Description of commerical industrial washing machine
Strong frame size: 70*70*6mm (thickness)
Front wall thickness 16mm
4mm thinkness stainless steel outer drum ensures strong and long time service
Main Specifications of commerical industrial washing machine
|
Model |
XGQ-100F |
|
rated capacity (dry loading |
100kg/230lb |
|
drum D×L (inner size) mm |
∮1240×840 |
|
cylinderD×L (inner size) mm |
∮1322×953 |
|
washing/distributing speed rpm |
30/60 |
|
middle/high extracting speed rpm |
350/680 |
|
work cycle min. |
45 |
|
motor power KW (frequency converting and speed changing) |
7.5 |
|
power of electric heating pipe kw |
|
|
steam pipe(DN) mm |
25 |
|
cool/hot water pipe(DN) (DN)mm |
40 |
|
water consumption of one cycle kg |
1800 |
|
steam consumption of one cycle kg |
50 |
|
power consumption of one cycle(frequency converting and speed changing) |
1.8 (steam) |
|
tap water pressure Mpa |
0.2-0.4 |
|
steam pressure Mpa |
0.4-0.6 |
|
work pressure of compressed air Mpa |
0.4-0.6 |
|
dimension (L×W×H) mm |
1920×1700×2020 |
|
machine weight |
2900 |
