Product Details:
Payment & Shipping Terms:
|
Name: | Barrier Washing Machine | Warranty: | One Year |
---|---|---|---|
Material: | Stainless Steel | Capacity: | 30kg, 50kg, 70kg, 100kg |
High Light: | commercial laundry equipment,industrial laundry machine |
1. The division plate of the barrier washing machine separates the drum into two parts, loading fromnon-clean zone”and unloading fromclean zone”.
2. It prevent bacteria and dust flow fromnon-clean zone”to ”clean zone”efficiently.Therefore, secondary pollution and cross-infection are impossible.
3. With touch screen controller or Siemens PLC, you can edit and change programs very easily.
4. Stainless Steel drum and panels for long time service.
5. frequency adjustable LS inverter and frequency controlled motor protect stable running.
Barrier Washing machine
The division plate of the barrier washing machine separates the drum into two parts, loading fromnon-clean zone”and unloading fromclean zone”. It prevent bacteria and dust flow fromnon-clean zone”to ”clean zone”efficiently. Therefore, secondary pollution and cross-infection are not exsited.
With computer controller, the barrier washer has the functions of auto/manual control, easy operation, efficent washing and good appearance.
The running speed is adjusted by inverter, which has the advantages of energy saving, anti-vibaration and low noise.
Specifications
Model |
BW-30 |
BW-50 |
BW-70 |
BW-100 |
Rated capacity |
30 |
50 |
70 |
85-100 |
Volume |
301 |
511 |
710 |
1000 |
Motor Power |
4 |
5.5 |
7.5 |
11 |
Washing speed |
40 |
40 |
40 |
30 |
Balancing Speed |
67 |
60 |
60 |
60 |
Mid-Extraction Speed |
375 |
340 |
340 |
340 |
High-Extraction Speed |
700 |
680 |
650 |
650 |
Compressed Air Pressure |
0.4-0.6 |
0.4-0.6 |
0.4-0.6 |
0.4-0.6 |
Water consumption |
1000 |
1200 |
1250 |
1800 |
Stream consumption |
20 |
30 |
45 |
50 |
Electricity Consumption |
1.5 |
2.1 |
2.8 |
3.2 |
Air Flow of Compressor |
0.36 |
0.36 |
0.36 |
0.36 |
Dimension |
1450×1530×1800 |
1710×1640×1875 |
1810×1750×2000 |
1810×1990×2150 |
Weight |
1300 |
1600 |
2400 |
3000 |
